FAAST XMTM incorporates advanced technologies and design features that easily overcome the application challenges associated with large area monitoring:

• The ability to monitor high ceilings up to 40m

• Flexible installation testing and maintenance to overcome access issues

• The ability to overcome smoke stratification and solar gain detection challenges via three-dimensional pipe networks that can be installed at different heights
• Flexible installation that compensates for building movement
• The ability to overcome compartmentalisation issues associated with warehouse/supermarket racking and shelves
• Discreet detection via capillary points and unobtrusive pipework that does not compromise aesthetics
• Safe and timely evacuations achieved by the earliest, most accurate warning of an issue

Warehouses, Distribution Centres & Supermarkets

When designing an ASD system for use in these environments, a number of potential issues should be considered.

For open warehousing, the recommendations given by local standards for spacing and height limits should be followed, with special consideration being given to the compartmentalisation that is determined by the racking/shelving.

FAAST XMTM features pipework that can be extended to provide maintenance test points at a low level, as shown in Figure 1 (top right).

Ceiling mounted sampling points should be positioned above the aisles wherever possible; particularly where the rack height is greater than 90% of the ceiling height.
